OUTGEAR SOLUTIONS

2005-2015 Tacoma Slim Series Swing Out

2005-2015 Tacoma Slim Series Swing Out

Regular price $2,500.00 USD
Regular price Sale price $2,500.00 USD
Sale Sold out
Style
StyleFuel/Water Can Holder



**We generally build for factory width, if you have FIBERGLASS - Email us your order! **

*** BED CAPS ARE INCLUDED ***

The Main bumper has the same features as our popular rear tube bumper, only difference will be the upper portion. Here's a quick run down:

Bumper will have - 2" Hitch receiver (Not Rated for Towing, however, we've seen many guys/gals pull watercrafts - dump trailers).

Slotted Tabs for light pods (Baja S2 will fit best), bed reinforcement tabs, and associated hardware.  Also included are 2 Body Filler Panels that goes underneath the Tail light.

The Bumper main plates are .375" Thick where it mounts and then becomes .750" thick to the outside of the round tubes to mount recovery or d rings.

The Round Tubes are all 1.75" DOM .120" thick

The Main Hitch receiver  is  2" ID and .1875" Thick, ties into the main frame plates to make everything structurally sound.

Includes LED Lights for your license plate.

Single Swingout: Swingout comes standard with Tire Mount to house up to 37s and molle panel style across swing out arm. Can mount License plate along the bottom of the arm, or on top.

Construction:

Double Sheared design, with 1 lock position point, Heavy Duty Custom Billet Compression latch, 2x3 rectangular tubing, .120" wall, 1.75" .120" Round DOM Tubing, and Short molle style paneling to house accessories like Tire mount, Camp Table, Hi Life, etc...

Add Ons/Accessories:

Stainless Steel Drop Table - TBA

Spare Tire License Plate Mount w/LED light $85

HiLift Jack Mount: $65

Recommend buying from 3rd party:

Rear Camera Relocation kit

Weight Without Tire / Accessories - 118lbs

Lead Times: ~14-16 weeks

We are ramping up additional team members to better serve you all, so lead times could be sooner!

Special Accommodations:

Please email us your order # for accessories you like to add so we can invoice you in future when your order is about almost ready.

Please email us if you have cut fenders or fiberglass width

**** Shipping:  ****

*** Shipping is extra, $250.00 flat rate at checkout (US Domestic) , AK+HI Extra $85 that will be invoiced separately ***

You can add few bumpers to save freight cost (pallet sharing) you just need to let us know your order #s.

If you need shipping elsewhere (HI, CANADA, AK, ETC..) Feel free to email us !

*** Powder Coating Services on larger orders (sliders/bumpers) are only available for local/will call. If your order requires shipping and  you order powder coat, we will apply the difference towards your freight bill (Powder subtract Bare Price). Sorry for this inconvenience! ***
